UVC MIRROR

Health is most important.

In todays world, we have become more and more concerned about hygiene. To protect others, ourselves and the ones we love.
We wash our hands, disinfect surfaces in our apartments, houses and at work, using chemicals harmful for us and the environment.
Until now … introducing the UVC Mirror, to automatically sanitize the sink, faucet and utensils on your vanity, using the latest technology in UV-lighting.


Mirror Type —

Lighting Design —


Mirror Width


Mirror Height

Features


Lighting Luminance


Lighting Color


Touch Controls

€755.00 *

incl. shipping costs

Available, ships within 75-90 days


Led lighting Easy to install Green product High brightness

UVC Mirror

HEALTH IS MOST IMPORTANT.



In todays world, we have become more and more concerned about hygiene. To protect others, ourselves and the ones we love. We wash our hands, disinfect surfaces in our apartments, houses and at work, using chemicals harmful for us and the environment. Until now … introducing the UVC Mirror, to automatically sanitize the sink, faucet and utensils on your vanity, using the latest technology in UV-lighting.

UVGI

HOW DOES UV DISINFECTION WORK ?



The process is called Ultraviolet germicidal irradiation (UVGI), which kills germs, bacteria and viruses such as COVID-19 by inactivation of their DNA. UVC light is a proven tool in the fight against disease-causing pathogens like viruses and bacteria.

ABSOLUTELY SAFE.

EFFECTIVE DISINFECTION.



Our patented design enables fully automatic disinfection without human intervention in a simple and cost-effective way and is absolutely safe. By utilizing UVC LED germicidal light, our mirror eliminates up to 99.99% (Log 4) of most common pathogens within seconds.

EQUIPPED WITH MOTION SENSOR OR A TOUCH PAD.

SAFETY FIRST.



Our solutions meet all the safety, lighting and design requirements for applications in hospitality, public spaces or healthcare. The UVC lights are off while you are using the mirror and turn on automatically after a preset time without movement. The UVC Mirror is equipped either with a motion sensor or a touch pad, to turn on and off the sanitation mode. The indicator on the mirror gives you additional feedback whether the lights are running.



EFFICIENCY

LABORATORY TESTED



The efficiency of UVC light in destroying these types of germs has been recounted in both research studies and field applications for decades.
Our UVC mirror has been successfully tested in the laboratory, which confirms its effectiveness and safety.

THE SPECIAL ENVIRONMENT OF BATHROOMS.

The bathroom is an area of high contamination. While efforts are made to properly disinfect they often fall short of total elimination of the most virulent contaminants. Studies have shown, that sinks and sink handles contain 600 times more microorganism than toilets. The sink area is directly in the „line-of-sight“ of the UVC mirror and therefore it most effectively kills germs, bacteria and viruses in this area; unlike standard UVC robots, which cannot reach areas such as the inside of the sink.

ACTIONABLE DATA CRITICAL TO ADMINISTRATORS

With the smart phone app, you can easily manage all the UVC Mirrors in your house or office, choose sanitation intensity, timer and many more things. It also gives you an overview how long the sanitation is running each day.

GERMICIDAL UV

DISINFECTING ROOM AIR WITH GUV



Upper-room GUV is a safe means of air disinfection that is possible in rooms with high ceilings. This upgrade adds another disinfection unit to your UVC Mirror for the upper part of your room. Upper-room GUV disinfects large volumes of room air (above occupants’ heads) at once, resulting in high „equivalent“ air changes per hour (ACH) in terms of air disinfection only—GUV does not dilute odors or CO2.

This upgrade requires an installation with a floor height of at least 210 cm for the room air disinfection unit.

TASK LIGHTING CONTROL

IN-MIRROR TOUCH CONTROL.



The easy to use Touch Control is seamlessly integrated into the mirror. Change the settings of your mirror at the touch of your fingers - no need to look for a light switch or a remote, simply direct your touch to the elegant touch keys on your mirror and enjoy the rare and elegant combination of style and comfort.

Several preset light levels that match your common lighting needs are available, such as:
· 100 % Bright lighting to help you with tasks
· 60 % Standard lighting to illuminate your room
· 20 % Soft lighting for a relaxing atmosphere

DIMMER

INTEGRATED TASK LIGHTING.



The UVC Mirror is available in different sizes, as well as designs and can come with task light as known from regular mirrors to dim and select your lighting color.

WE GIVE YOU CONFIDENCE

LIGHTING COLOR



With our luxury LED lights you can select the color that best matches the environment you’re preparing for – outdoors, indoors, or evening – in a range between 2700 K to 6500 K.

TASK LIGHTING

REAL COLORS



Light sources with a high CRI are desirable in color-critical applications such as your make up for a perfect look.
We offer the highest possible industry standard for LEDs with a CRI value of more than 90.

TASK LIGHTING

LUMINANCE



We offer the densest LED bulbs count per meter, resulting in the highest quality and brightest possible lighting to fulfill your tasks. And best of all: dim the illuminance according to your wishes with a fingertip via the touch keys inside the mirror. ad notam only uses LEDs that have an effective lifespan of at least 50,000 hours.

TASK LIGHTING

DIRECT ILLUMINATION



Forget shadows and insufficient light on the lower face and neck; ad notam direct illumination places sufficient lights on the hairs, face and neck for an optimal make up. With our direct illumination technology you get the brightest possible lighting for your mirror. Compared to other lighted mirrors, we achieve up to 100 % more Lumen Output or vice versa less power consumption for a defined Lumen Output.

TASK LIGHTING

SERVICEABLE AND REPLACABLE LED BARS



For us at ad notam, the longevity of the products is important. For most LED products, the bulbs cannot be replaced. With our unique lighting design we offer the possibility to replace the bulbs, so that your investment pays off for many years.

MIRROR DEFOGGER

ALWAYS A CLEAR VIEW.



The integrated mirror defogger prevents the mirror surface from steam condensation in wet environments, providing a fogless mirror with clear vision at all times. If not needed, the mirror defogger can be switched off in order to save energy.

*

The prices are non-binding recommendations from the manufacturer, excluding VAT. Subject to changes and errors.

Technical details

Materials

Crystal mirror combined with anodized aluminium
Lighting pattern possible as stripes

Dimensions

Different sizes available
Width (W) in mm 600 | 900 | 1.200 | 1.600
Height (H) in mm 900
Depth (D) in mm 45

Weight

in kg for the basic model without upgrades
W 600 | H 900: 10,4 kg
W 900 | H 900: 13,8 kg
W 1200 | H 900: 17,2 kg
W 1600 | H 900: 21,7 kg

Product Usage: For In-Door Use only
Operating Temperature: 5° to 40° Celcius
Humidity: 20 % - 80 %
HS Code: 70 09 91 00
Storage Temperature: -10° to 60° Celcius
Packaging type: Carton Box
Packaging dimensions:
W (Product Width + 125) x H 1015 x D 150 mm

Certification

iCL II, IP44, Vol 2 et 3; IPX4; CE; CB rate; COV; Rohs

CRYSTAL MIRROR
Standard
Thickness: 5 mm
Surface: Float
Tint: Neutral
Reflection: 95 % +/- 5
Sensor Area: Visible

  Mirror Width 600 mm Mirror Width 900 mm Mirror Width 1200 mm Mirror Width 1600 mm
Projected Surface Width: 300 mm 600 mm 900 mm 1200 mm
Projected Surface Depth: 480 mm 480 mm 480 mm 480 mm
Number of UV-C LEDs: 15 30 45 60
Number of UV-A LEDs: 5 10 15 20
UV-C Wavelength: 275 nm 275 nm 275 nm 275 nm
UV-A Wavelength: 400 nm 400 nm 400 nm 400 nm
UV-C Radiation Power: ≥ 37.5 mW ≥ 75 mW ≥ 112.5 mW ≥ 150 mW
Beam Angle: 60° 60° 60° 60°
Max. Radiation Intensity: 403 uW/cm2 @ 25 cm 403 uW/cm2 @ 25 cm 403 uW/cm2 @ 25 cm 403 uW/cm2 @ 25 cm
Avg. Radiation Intensity: 174 uW/cm2 @ 25 cm 174 uW/cm2 @ 25 cm 174 uW/cm2 @ 25 cm 174 uW/cm2 @ 25 cm
Power Consumption: 3 W 6 W 9 W 12 W
Current Consumption: 125 mA 250 mA 375 mA 500 mA

Germidical Effectiveness
99% reduction (Log2 @ 10 mJ/cm2): 57 seconds (Avg.) @ UVC Mirror installed at 200 mm above surface
99,99% reduction (Log4 @ 20 mJ/cm2): 115 seconds (Avg.) @ UVC Mirror installed at 200 mm above surface


Standard
Type: LED, direct - one layer 120 LED/m
Color: 4100 K
Viewing Angle: 120°
Color Rendering Index (CRI): 90+
Dimmer: no
Power: DC 24 V / Default: 9.6 W per running meter of LED

Upgrade
Type: LED, direct - double layer 240 LED/m
Color: 2700 K - 6000 K, changeable
Viewing Angle: 120°
Color Rendering Index (CRI): 90+
Dimmer: yes, 5 steps
Power: DC 24 V / Default: 19.2 W per running meter of LED

Light efficiency (lumen flux) Please refer to the following table, values in lumen +/- 5 %

WL T01-S Series – 1-sided Lighting
W 600 | H 900: Standard - 487; Upgrade - 974
W 900 | H 900: Standard - 739; Upgrade - 1478
W 1200 | H 900: Standard - 991; Upgrade - 1982
W 1600 | H 900: Standard - 1327; Upgrade - 2654

WL S02-S Series – 2-sided Lighting
W 600 | H 900: Standard - 1478; Upgrade - 2956
W 900 | H 900: Standard - 1478; Upgrade - 2957
W 1200 | H 900: Standard - 1478; Upgrade - 2958
W 1600 | H 900: Standard - 1478; Upgrade - 2959

WL TS03-S Series – 3-sided Lighting
W 600 | H 900: Standard - 1966; Upgrade - 3932
W 900 | H 900: Standard - 2218; Upgrade - 4436
W 1200 | H 900: Standard - 2470; Upgrade - 4940
W 1600 | H 900: Standard - 2806; Upgrade - 5612

Type: The sensor is an active motion detector; it emits a high-frequency electromagnetic wave 5.8 GHz and receives its echo. The sensor detects the change in echo from movement in its detection zone.
Hf System: 5.8 GHz CW radar
Transmission Power: < 0.2 mW
Detection Angle: 30° – 150°
Detection Range: Max. 12 m in diameter, adjustable

Mirror Width 600 mm
Size: 200 x 300 mm
Power: 11 W, 0.05 A
Voltage: AC 220 V

Mirror Width 900 mm
Size: 400 x 400 mm
Power: 28 W, 0.13 A
Voltage: AC 220 V

Mirror Width 1200 mm
Size: 800 x 400 mm
Power: 56 W, 0.26 A
Voltage: AC 220 V

Mirror Width 1600 mm
Size: 800 x 400 mm
Power: 56 W, 0.26 A
Voltage: AC 220 V

Type: Lighting Control & Mirror Defogger
Technology: Capacitive

ad notam
Standard
Number of keys: 0
Functions: N/A

TC-01-MD 1
Upgrade
Number of keys: 1
Functions: Mirror Defogger ON/ OFF

1 only in combination with Mirror Defogger upgrade

TC-01-LC 2
Upgrade
Number of keys: 1
Functions: Short Press: Dimmer | Long Press: Change Color

2 only in combination with Dimmer upgrade

TC-02-MDLC 3
Upgrade
Number of keys: 2
Functions: Key 1: Mirror Defogger ON/OFF Key 2: Short Press: Dimmer | Long Press: Change Color

3 only in combination with Mirror Defogger and Dimmer upgrade
